Dual PTT
VOX Function
CE Certificated
Scanning function
Wireless copy frequency
Type-C charger port
Easy back clip design
GENERAL
Frequency
UHF:400-470MHz
Channel capacity
16
Channel space
12.5KHZ
Frequency stability
±2.5ppm
Voltage
3.7vdc
Antenna impedance
50Ω
Work temperature
-20℃ to +50℃
Battery capacity
4800mAh
Size(include battery, exclude antenna)
130x60x30mm
Weight(include battery and antenna)
80g
TRANSMITTER
Output power
2W
Modulation limit
+2.5kHz@12.5kHz
FM Hum & Noise
≤45dB
Modulation maximum deviation
≤5KHz
RECEIVER
Sensitivity (12 dB SINAD)
8-12mW
Adjacent channel selectivity
≥65dB
Audio output power
≥350mw
Audio distortion
<10%
