Functions:
-PC programming
-DTMF function, 2 tone, 5 tone
-ANI (caller ID)
-FM radio
-Single band/Quad standby
-Remote stun, remote activate, remote revive
-Long distance communication
-VHF 100W / UHF 75W high output power
General Specification |
Memory Channel | VHF: 256 Channels UHF: 200 Channels |
Antenna Impedance | 50Ω |
Work Mode | Simplex |
Channel Spacing | 25KHz, 20KHz, 12.5KHz |
Squelch Way | CARRIER / CTCSS / DCS / 5Tone / 2Tone / DTMF |
Weight | 1.03kg |
Dimension | 13.8V |
Transmitter |
Frequency Range | VHF:136-174MHz UHF:400-480MHz |
Output Power | VHF ≤ 100W, UHF ≤ 75W |
Type of Modulation | 16kΦF3E / 11kΦF3E |
Maximum Deviation | ≤5kHz/≤ 2.5kHz(W/N) |
Residual Radiation | 60dB |
Emissions Current | ≤3.5A |
Audio Distortion | ≤5% |
Receiver |
Frequency Range | VHF:136-174MHz UHF:400-520MHz |
Sensitivity | <0.18μV |
Audio Power | ≥500mW |
Audio Distortion | ≤5% |
Intermodulation | ≥60dB/≥ 55dB |
