25W Dual-Band Mobile Radio (FCC&CE)

  • Product Origin:

    China
  • Item NO.:

    VV-898S
  • Shipping Port:

    Xiamen/Shenzhen
  • Color:

    Black
  • Payment:

    T/T
  • MOQ:

    10
Product Detail

Functions:

-Dualband Transmit (136-174MHz and 400-480MHz)

-Dual PTT/Dual Waiting

-Reverse/RPT Offset/1750Hz

-PPTID

-DTMF Encode/Decode

-Single Call/Group Call

-Romote Kill/Romote Stun

-Non-Standard CTCSS/DCS

-Scrambler

-Compact Dimensio


General Specification

Memory Channel

199

Antenna Impedance

50Ω

Work Mode

Simplex

Weight

315g

Dimension

13.8V

Transmitter

Frequency Range

VHF:136-174MHz UHF:400-480MHz

Output Power

5W/10W/25W

Type of Modulation

16kΦF3E / 11kΦF3E

Maximum Deviation

5kHz/ 2.5kHz(W/N)

Residual Radiation

60dB

Emissions Current

≤3.5A

Audio Distortion

≤5%

Receiver

Frequency Range

VHF:136-174MHz UHF:400-520MHz

Sensitivity

<0.18μV

Audio Power

≥500mW

Audio Distortion

≤5%

Intermodulation

60dB/ 55dB
