VOX function
Voice prompt
Channel Scan
Power Save
Low battery alarm
Wireless Frequency Copy
Type-C Battery (Optional)
GENERAL
Frequency
400-470MHz
Channel capacity
16
Channel space
12.5KHZ
Frequency stability
1.25ppm
Voltage
7.4vdc ±20%
Antenna impedance
50Ω
Work temperature
-25℃ to +60℃
Battery capacity
2800mAh
Size(include battery, exclude antenna)
140 x40 x 60 mm
Weight(include battery and antenna)
612g
TRANSMITTER
Output power
5W
Modulation limit
≤±5KHz/25kHz
FM Hum & Noise
45dB@25KHz
Modulation maximum deviation
≥70db
RECEIVER
Sensitivity (12 dB SINAD)
0.20uV @12.5KHz/25KHz typical
Adjacent channel selectivity
65dB@20/25KHz
Audio output power
≥400mW
Audio distortion
5%@1W
