32 channels
High and low power switching
Supports full/group/single calling
Scan, mute, monitor
Alarm function, personnel falling alarm
High definition voice
Digital encrypted communication
Dual time slots
IP67 waterproof
GENERAL
Frequency
136-174MHZ/400-470MHZ
Channel capacity
32
Channel space
12.5KHZ
Frequency stability
±1.0ppm
Voltage
7.4vdc
Antenna impedance
50Ω
Work temperature
-30℃ to +60℃
Battery capacity
2800mAh
Size(include battery, exclude antenna)
123x63x39mm
Weight(include battery and antenna)
322g
TRANSMITTER
Output power
5W
4FSK Digital Mode
12.5KHZ(data only): 7k60FXD
FM Hum & Noise
-40dB@12.5KHZ
Modulation maximum deviation
2.5KHZ@12.5KHZ
RECEIVER
Sensitivity (Digital)
0.3uV/-117.4dBm
Adjacent channel selectivity
TIA603C:65dB ETS:60dB
Audio output power
1W
Audio distortion
3%(Type)
