Working Frequency (TNZ800-01-EU)

TDD-LTE: B38/B39/B40;

FDD-LTE: B1/B3/B7/B20/B28A/B28B

Working Frequency (TNZ800-02-US)

GSM: B2/B3/B5/B8

WCDMA:  B1/B2/B5/B8

FDD-LTE: B2/B4/B5/B12/B13/B17

Working Frequency (TNZ800-03-EU)

GSM: B2/B3/B5/B8

WCDMA:  B1/B2/B5/B8

TDD-LTE: B38/B39/B40

FDD-LTE: : B1/B3/B7/B20/B28

Working Frequency (TNZ800-06-US)

GSM:  B2/B3/B5/B8

WCDMA:  B1/B2/B5/B8

TDD-LTE: B38

FDD-LTE: B2/B4/B5/B7/B12/B13/B17/B28AB28B

Working Voltage

DC 3.3~4.2V

Working Current

Power Off: <20uA; Sleep mode: <3mA

Working Temperature

-30°C~+75°C

Rated Audio Output Power

1.3W

Max Output Power

24dBm~33dBm,+2dBm

Audio Distortion@ Rated Audio

10%

General Specifications

Platform

MTK MT6737WM

Operate system

Android 7.0

Camera

Front(5MP)and Rare(8MP)

Memory

8GB(ROM)+1GB(RAM)

Extended Memory

Up to 32GB

Speaker & earhpone connector

M6

GPS

Support

battery capacity

3500mAh

Dimensions

180*65*24(mm)

Weight

262g
