Frequency

400-520MHz/136-174MHz

Channel capacity

199

Channel space

Same frequency simplex

Frequency stability

±2.5ppm

Voltage

4.2vdc +15%

Antenna impedance

50Ω

Work temperature

-20℃ to +60℃

Battery capacity

1800mAh

Size(include battery, exclude antenna)

110x61x32.45mm

TRANSMITTER

Output power

3W

Preemphassis Character

6dB

Maximum frequency deviation

≤5KHz

Modulation Distortion

≤5%(300-3000Hz)

FM Noise

-45dB

SNR(signal-to-noise ratio)

40dB

Frequency deviation

≤±5KHz

Freuency Characteristic

±3dB

RECEIVER

Sensitivity (12 dB SINAD)

0.22uV/0.25uV

Adjacent channel selectivity

55dB

Audio output power

1W

Audio distortion

<5%

Modulation Type

F3E
