Type-C charging port
Compact and Light
SOS function
Alert Flash Light
Wireless Frequency Copy
Scrambler function
Al Noise-Reduction (Optional)
GENERAL
Frequency
400-520MHz
Channel capacity
16
Channel space
12.5/25KHZ
Frequency stability
±25ppm
Voltage
7.4vdc
Antenna impedance
50Ω
Work temperature
-25℃ to +60℃
Battery capacity
1800mAh
Size(include battery, exclude antenna)
112x 54 x 30 mm
Weight(include battery and antenna)
180g
TRANSMITTER
Output power
5W
Adjacent channel power
≤65dB
Signal Noise Ratio
≥45dB
Transmitting current
≤1500mA
RECEIVER
Sensitivity (12 dB SINAD)
-122dBm
Adjacent channel selectivity
≥55dB
Audio output power
≥350mW
Audio distortion
＜10%
